Sokkia SET2X total station total station is a rugged, high performance that incorporates the latest technology with traditional surveying functionality. An environmental protection degree IP65 SET X marks the highest in class for Windows CE total stations, allowing it to withstand the harsh conditions of the most demanding workplaces. SET X is available in 1 ', 2', 3 'and 5' models for use in a wide range of positioning applications. 1 'and 2' models include absolute encoders enhanced with Sokkia innovative system Independent Angle Calibration (IACS ) to provide extremely reliable angle measurement with unprecedented stability The article includes Total Station SET2X Ion - battery ( 2 pcs.
- Sokkia Set2x Total Station English Manual For Honda
- Sokkia Set2x Total Station English Manual Of Style
) Charger and power cable BDC58 BDC46 adapter to size tubular compass sunshade Stylus Pen ( quantity 2) Lens Cap Plumb Bob Toolkit Operations Manual Hard Case Manufacturer Warranty 2 years Windows CE. Expandable Windows CE installed SET X has an easy to see color LCD touch-screen operation and put in a class by itself.
SDR Program Board SDR program is a collection of software based on Windows CE data increases functionality by providing powerful surveying programs with an easy to follow workflow, customizable settings and a graphic interface. The best in class for the Protection of the Environment SET X offers the highest in environmental protection for Windows CE total stations. SET X has an IP65 rating, which means it is able to withstand the harshest conditions in the most demanding workplaces.
SET X maintains its IP65 rating even with the external battery connected. RED-tech EX - High measurement accuracy reflectorless technology Use of digital signal processing Revolutionary RED-tech EX EDM is acclaimed for high accuracy using a red laser beam ultra thin and flexible as the shortest distance industry 30 cm (1ft.) to 500 m (1640 ft). RED-tech EX performs accurate reflectorless measurement of building corners, telephone / electrical wires, records, and even through fences. Measurement of beam spot size (so no reflector) Distance 2m (6.6 feet).
10m (33ft.) 40m (131ft.) Measuring beam spot size (Height u00d7 Width) 5 u00d7 7mm (0.2 u00d7 0.28in.) 7 u00d7 9mm (0.28 u00d7 0.35in.) 14 u00d7 14mm (0.55 u00d7 0.55in.) Distance 100m (328 ft) 300m (984ft.) 500m (1640ft.) Measuring beam spot size (W high u00d7) 29 u00d7 24mm (1.14 u00d7 0.95in.) 76 u00d7 56mm (2.99 u00d7 2.2in.) 123 89mm u00d7 (4.84 u00d7 3.5 inches). Optimized Single Beam RED-tech EX uses only one laser beam for distance measurement and pointing, meaning it exactly measures the red laser dot. The laser beam diameter and output level are automatically optimized for the target type providing stability that you have never experienced before. Long Distance Measure Measure distances of up to 6000 m (19,680 ft) using a single AP prism and 500m (1640 ft) with reflective targets.
Angle Measurement System Advanced SET X features SOKKIA's original absolute encoders that provide long-term reliability in the conditions of the workplace. SET1X and SET2X feature innovative IACS (Independent Angle Calibration System) technology for extremely reliable angle measurement. The trigger SET X features an ergonomically placed trigger key that greatly facilitates taking measurement while looking through the telescope and even while turning the fine motion screws. The measurement can be taken at any time by pressing a button.
Bluetooth ® Wireless Technology Enjoy a wireless connection with your data collector or tablet PC for expanded data collection possibilities and seamless data handling. 1 Bluetooth wireless technology provides license communication Class reflectorless 200m side up. Multiple memory options SET X has 1 MB of internal memory, CF card slot and USB.
A 1GB SD card can also be used with an adapter. SFX The SOKKIA original SFX technology provides convenient data transfer anywhere in the world via a mobile phone with Internet capability. Light Guide An easy to see the light guide helps you configure the measurements. Green and red LED's visually guide the operator side prism Reviews.
Sokkia Set2x Total Station English Manual For Honda
Sokkia SET2X 2″ total station the SET2x total station has an angle accuracy of 2″ / 0.6mg and includes absolute encoders enhanced with Sokkia innovative system Independent Angle Calibration (IACS) to provide extremely reliable angle measurement with unprecedented stability. Sokkia SET2X 2″ total station Sokkia SET2X total station is a rugged, high performance that incorporates the latest technology with traditional surveying functionality. An environmental protection degree IP65 SET X marks the highest in class for Windows CE total stations, allowing it to withstand the harsh conditions of the most demanding workplaces. SET X is available in 1 “, 2”, 3 “and 5” models for use in a wide range of positioning applications. 1 “and 2” models include absolute encoders enhanced with Sokkia innovative system Independent Angle Calibration (IACS) to provide extremely reliable angle measurement with unprecedented stability Windows CE. Expandable Windows CE installed SET X has an easy-to-see color LCD touch screen display and its operability puts it in a class of its own.
SDR Program On-board SDR program is Windows CE-based data collection software that increases functionality by providing powerful surveying programs with an easy-to-follow workflow, customizable settings and a graphic interface. Highest in its Class for Environmental Protection SET X offers the highest in environmental protection for Windows CE total stations. SET X has an IP65 rating, meaning it is able to withstand the harshest conditions in the most demanding jobsites.
SET X maintains its IP65 rating even with the external battery connected. RED-tech EX – High Precision Reflectorless Measurement Using Revolutionary Digital Signal Processing Technology RED-tech EX EDM is acclaimed for pinpoint accuracy using an ultra-narrow red laser beam and for the flexibility to measure from the industry’s shortest distance of 30cm (1ft.) up to 500m (1,640ft.).
RED-tech EX performs accurate reflectorless measurement of building corners, telephone/electrical wires, manholes, and even through fences. Measuring beam spot size (Reflectorless mode) Distance 2m (6.6ft.) 10m (33ft.) 40m (131ft.) 100m (328ft.) 300m (984ft.) 500m (1,640ft.) Beam spot size (height x width) 5 x 7mm (0.2 x 0.28in.) 7 x 9mm (0.28 x 0.35in.) 14 x 14mm (0.55 x 0.55in.) 29 x 24mm (1.14 x 0.95in.) 76 x 56mm (2.99 x 2.2in.) 123 x 89mm (4.84 x 3.5in.) Single Optimized Beam RED-tech EX uses only one laser beam for distance measurement and pointing, meaning it exactly measures the red laser point. The laser beam diameter and output level are automatically optimized according to the target type providing stability that you have never experienced before. Long Distance Measurement Measure distances up to 6,000m (19,680ft.) using a single AP prism and 500m (1,640ft.) using reflective sheet targets.
Sokkia Set2x Total Station English Manual Of Style
Advanced Angle Measurement System SET X features SOKKIA’s original absolute encoders that provide long-term reliability in any work-site conditions. SET1X and SET2X feature groundbreaking IACS (Independent Angle Calibration System) technology for extremely reliable angle measurement. Trigger Key SET X features an ergonomically placed trigger key that greatly facilitates taking measurement while looking through the telescope and even while turning the fine motion screws. Measurement can be taken at any time with just the push of a button.
Bluetooth® Wireless Technology Enjoy a wireless connection with your data collector or tablet PC for expanded data collection possibilities and seamless data handling. Class 1 Bluetooth wireless technology provides license-free prism-side communication of up to 200m. Multiple Memory Options SET X has 1MB of internal memory, CF card slot and USB ports. A 1GB SD card can also be used with an adapter.
SET2X Reflectorless Total Station Specifications SETX Reflectorless Total Stations Model SET2X Laser output Reflectorless mode: Class 3R (max. 5W) Prism / Sheet mode: Class 1 equivalent (max.
